Control System : +Pulse Width Control 1500usec Neutral
Required Pulse : 3-5 Volt Peak to Peak Square Wave
Operating Voltage : 4.8-6.0 Volts
Temperature Range : -20 to +60 Degree C
Operating Speed (4.8V) : 0.19sec/60° at no load
Operating Speed (6.0V) : 0.15sec/60° at no load
Stall Torque (4.8V) : 42 oz/in (3.0 kg/cm)
Stall Torque (6.0V) : 49 oz/in (4.5 kg/cm)
Current Drain (4.8V) : 7.4mA/idle, 160mA no load operating
Current Drain (6.0V) : 7.7mA/idle, 180mA no load operating
Dead Band Width : 5usec
Operating Angle : 40° one side pulse traveling 400usec
Direction : Clockwise/Pulse Traveling 1500 to 1900usec
Motor Type : Cored Metal Brush
Potentiometer Drive : 4 Slider/Direct Drive
Bearing Type : Top/Resin Bushing
Gear Type : Nylon
360 Modifiable : Yes
Connector Wire Length : 11.81" (300mm)
Weight : 1.52oz (43g)
Servo Motor HS-311 Standard
